16 Tons Wheel Rim Shell for Dongfeng T-Lift Truck Spare Parts 2405010-ZH04D

16 Tons Wheel Rim Shell for Dongfeng T-Lift Truck Spare Parts 2405010-ZH04D

product description:

(1) The accuracy of the oil seal, seam, steel ring position, etc. is 1/3 higher than that of the market wheel rim (for example, the tolerance of the Fukai brand oil seal is 0~8 wires, and the tolerance of the ordinary wheel rim is 0~15 wires).

(2) The disc surface is drilled with a reamer, and the position of the tire hole is checked with a inspection tool disc to ensure the consistency of the hole diameter and perfect concentricity.

(3) In order to prevent one ten thousandth of oil leakage, the machining center uses a rough boring and fine boring process to make the shaft hole; the 10 threaded holes at the bottom of the rim housing are all blind holes (most rims on the market for through holes).

(4) When drilling the legs of the wheel rim planet carrier, in order to prevent the angle from becoming skewed when the hole is deep, thereby reducing the service life of the planet carrier after assembling the wheel rim assembly, the Fuka brand wheel rim shell is first processed in the machining center Drill the hole to position 2.5mm, and then drill vertically to complete it (most brands of planetary carriers are directly made in one go).

(5) After the wheel edges are formed, they are polished one by one with metallographic instruments and inspected individually before shipment to ensure the stability of the material of each product.

Working principle of wheel reducer assembly:

The wheel reducer is mainly composed of a sun gear, a planet gear, a ring gear and a planet gear carrier. Generally, the sun gear, the active part, is connected to the half shaft, the planet gear carrier, the passive part, is connected to the wheel, and the ring gear is connected to the axle housing. The purpose of using a wheel reducer is to improve the driving force of the car to meet or correct the force of the entire transmission system. match. The wheel reducer currently used is a set of gear transmission devices that reduce speed and increase torque to meet the matching needs of the entire transmission system. The power is transmitted from the engine to the main reducer of the front and rear axles through the clutch, transmission and transfer case, and then from the output end of the main reducer to the wheel reducer and wheels to drive the car. In this process, the working principle of the wheel reducer is to transfer the speed and torque transmitted by the main reducer to the wheels after reducing the speed and increasing the torque, so that the wheels can produce a larger force under the reaction of the ground adhesion. driving force. This reduces the stress on the parts in front of the wheel reducer.

Basic Info.

Product selling point

(1) The main machine is assembled with supporting parts and components, with stable and reliable quality.

(2) The wheel rim shell is processed by the machining center, the wheel rim assembly is assembled on the assembly line, and a single inspection is carried out from the warehouse.

(3) Unified coding and clear identification of drawing numbers improve the traceability of wheel rim assemblies.

(4) Brand integrated carton, inner bag, and integral foam packaging, strong and beautiful.

quality assurance:

Vertical lathe machining center - CNC center - Boring machining center - High-precision grinder - Metallographic inspection - Automated three-coordinate inspection

Q1. Are you a factory or trading company?
We are a factory integrating research, development, production and sales.

Q2. What are the advantages of your products?
We support product customization to meet customer needs for special products. We can strictly control the products from raw materials to production, processing, product quality inspection, delivery, packaging, etc., and provide customers with high-end products and the most advantageous prices.

Q3. How about products price?
We are a factory, all products are direct sale at factory price. For the same price, we will provide the best quality; for the same quality, we have the most advantageous price.

Q4. What is your terms of packing?
We have branded packaging and neutral packaging, and we can also do what you want with authorization. This is flexible.

Q5. How to guarantee your after-sales service?
Strict inspection during production, Strictly check the products before shipment to ensure our packaging in good condition. Track and receive feedback from customer regularly. Our products warranty is 365 days.
Each product provides quality assurance service. If there is a problem with the product within the warranty period, the customer can negotiate with us in detail about the related claims, and we will do our best to satisfy the customer.

Q6. How can I accurately buy the products I need?
We need accurate product number, If you can't provide product number, you can send us your product picture, or tell us your truck model, engine name plate, and so on. we will
determine exactly what you need products.

Q7. Do you accept third party inspection?
Yes.we do

Q8. How about your delivery time?
Generally, it will take 3 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q9. What are your brand agency conditions and advantages?
After we sign an agent in one city, we will not sign a second company to protect the agent's brand advantage and price advantage. And we will help the agent develop customers and solve all kinds of difficult and miscellaneous problems about products.

Q10. What is your terms of payment?
By TT or LC. We'll show you the photos of the products and packages before you pay the balance.

Certificate
